Manufactured by RICHENG Technology (Shenzhen), the YC133LCE30-A54 is a 13.3" Full HD TN TFT LCD module with an eDP interface — a thin (5.14mm), landscape panel suited to portable monitors, thin-and-light devices, and other laptop-adjacent applications.
Key specifications
| Parameter | Value |
|---|---|
| Screen size | 13.3" diagonal |
| Resolution | 1920×1080 (Full HD) |
| Panel type | TN TFT |
| Display colors | 16.7M |
| Contrast ratio | 1000:1 (typ) |
| Brightness | 800 cd/m² (typ) |
| Viewing angle (L/R/U/D) | 89° / 89° / 89° / 89° |
| Response time | 25ms |
| Interface | eDP 1.2 |
| Color gamut | NTSC 72% |
| Surface treatment | Anti-glare coating, 3H hardness |
| Outline dimension | 306.86 × 182.38 × 5.14 mm |
| Active area | 293.76 × 165.24 mm |
| Pixel pitch | 0.153 × 0.153 mm |
| Operating temperature | -10°C to 50°C |
| Storage temperature | -20°C to 70°C |
TN panel, near-IPS viewing angle numbers
This is a TN (twisted nematic) panel rather than IPS, which typically carries a cost advantage — but its measured viewing angle (89° in all four directions at CR≥10) is close to what IPS panels deliver on paper. If your application involves off-axis viewing, ask for a sample to evaluate color consistency at the angles that matter for your specific use case, since TN and IPS can still differ in how color shifts (not just contrast) at extreme angles even when the raw CR≥10 numbers look similar.
Interface & driving
- eDP 1.2 electrical interface — the standard choice for laptop-class and portable-monitor driver boards
- Logic supply voltage 3.0–3.6V (typ 3.3V), typical current draw 180mA
- 3H anti-glare coating for reduced reflection under typical indoor lighting
Typical applications
Portable external monitors, thin-and-light device panels, and other landscape Full HD applications where eDP interface compatibility and an 800 cd/m² brightness ceiling matter.
Sourcing a 13.3" eDP panel for a portable monitor or thin device? Request a quote with your requirements.
