Manufactured by RICHENG Technology (Shenzhen), the YC069IM30P is a 6.9" (7.0" per datasheet) portrait TFT LCD module with a wide 75°–85° viewing angle in all four directions — sized and shaped for handheld devices, compact terminals, and other phone-class form factors.
Key specifications
| Parameter | Value |
|---|---|
| Screen size | 6.9" (7.0" diagonal per datasheet) |
| Resolution | 600×1024 (portrait, RGB stripe) |
| Display mode | Normally Black, transmissive |
| Contrast ratio | 800:1 (typ) |
| Brightness | 350 cd/m² (typ) |
| Viewing angle (all directions) | 75° min / 85° typ, CR≥10 |
| Response time | 10–20ms (rise) / 15–30ms (fall) |
| Interface | 30-pin MIPI |
| Dot pitch | 0.0496 × 0.1488 mm |
| Active area | 89.28 × 152.37 mm |
| Module dimension | 95.06 × 136.3 × 2.4 mm |
| Surface treatment | Hard coating |
| Operating / storage temp | Refer to reliability test section |
A phone-class panel with a genuinely wide viewing angle
At 75°–85° of usable viewing angle (contrast ratio ≥10) in every direction, this panel holds up well off-axis — useful for handheld devices that get viewed at an angle as often as straight-on, or wall/desk-mounted compact terminals where users approach from varying heights.
Interface & driving
- 30-pin FPC, MIPI interface with a dedicated clock pair and 4 data lanes
- Configurable scan direction (horizontal and vertical inversion pins) for flexible mounting orientation
- Hard-coated surface for improved scratch resistance versus an untreated polarizer
Typical applications
Handheld terminals, compact instrumentation, portable devices, and other phone-class products where portrait orientation and wide-angle consistency matter.
Need this panel with a custom cover lens or touch layer? Request a quote with your requirements.
